| Description: | 24- Panel 16.75 kW Premium Grid-Tie Solar System
• (24) 698 Watt (BSTC), Bifacial Monocrystalline Solar Panels, Industrial Grade.
• (1) Fronius Inverter, UL 1741 Certified, Nema 4x, Includes DC disconnect. Capable of online monitoring if connected to the internet.
• (1) Fronius Data Manager included which enables on-line performance monitoring and alerts.
• (1) Manual AC Disconnect Switch (Customer connection point).
• AC Output: 15.0 kW, 208/240 Volt, Single Phase, 60 Hz.
• All components listed above to be mounted on (2) galvanized steel frameworks and are prewired together according to National Electrical Code (NEC). Units completely assembled prior to shipping from factory.
• Approximate Unit Dimensions: 45'L x 13'3"W x 11'10"H (folds to x 8'6"W x 9'7"H for transporting).
*Note: Shipping, anchoring, installation, permitting, and sales tax (if applicable) are not included and are quoted separately. This unit is for Grid-Tie applications only and does not operate as a backup power source.
These systems are fully customizable, and we can support up to 10 megawatts (MW) commercial solar projects. |
